Why Motor Topology Still Matters
Electric motors convert electrical energy into mechanical motion — a deceptively simple statement that belies an extraordinary breadth of topologies, materials science, and electromagnetic design. The global electric motor market is large and growing — most industry analysts publish multi-hundred-billion-dollar TAMs and high-single-digit CAGRs, with figures varying by methodology and segmentation. Yet most engineers interact with only one or two motor families throughout their careers.
This guide surveys the full landscape: from mature, mass-produced radial flux machines to exotic soft actuators that blur the boundary between motor and muscle. Each section examines the underlying physics, key design trade-offs, and where the technology excels — drawing on peer-reviewed papers, company publications, and verified datasheets where they exist, and clearly flagging where a number is vendor-reported rather than independently verified.
The Workhorse: Radial Flux BLDC Motors
The radial flux motor is the most ubiquitous electric machine on Earth. In this topology, magnetic flux travels radially across the air gap between a cylindrical stator (outside) and rotor (inside). Permanent magnets on the rotor interact with electromagnets wound on stator teeth to produce torque.
Design Principle: The stator consists of laminated silicon-steel stampings stacked axially, with concentrated or distributed copper windings inserted into slots. The rotor carries surface-mounted or interior permanent magnets (IPM). In IPM designs, reluctance torque supplements magnet torque, enabling field-weakening operation at higher speeds — a critical advantage for EV traction motors.
Key engineering decisions include slot-pole ratio (affects cogging torque and winding factor), magnet grade selection (N35 vs N52 NdFeB, trading cost for flux density), and cooling strategy (air, liquid jacket, or direct oil spray on end-windings). The radial topology excels in scalability: the same electromagnetic principles work from a 5mm drone motor to multi-MW ship propulsion units.
Limitations: The cylindrical geometry means power scales with both diameter² and axial length, making very high-torque, compact designs difficult. Comparative studies show radial flux motors are typically heavier for equivalent torque versus axial designs, though the exact penalty depends on application constraints.
Radial flux BLDC, 12-slot / 8-pole reference layout. Magnets on the rotor exchange flux radially across the air gap with stator teeth carrying concentrated copper windings. The stator yoke (back-iron) closes the magnetic circuit on the outer ring.
Flat & Powerful: Axial Flux Machines
Axial flux motors flip the geometry: instead of a cylindrical air gap, the flux travels axially between flat disc-shaped stator and rotor surfaces. This pancake form factor delivers exceptional torque density because the entire active diameter contributes to torque production simultaneously.
Design Principle: A typical dual-rotor, single-stator configuration sandwiches a wound or PCB stator between two magnet-carrying rotor discs. Yokeless designs eliminate the back-iron return path entirely, saving significant mass.
The short axial length makes axial flux motors well suited to space-constrained applications: in-wheel motors for EVs, direct-drive wind turbines, and aerospace actuators. Mercedes-Benz publicly demonstrated an axial flux rear motor in the Vision EQXX concept vehicle as part of a broader efficiency program.
Challenges: Manufacturing complexity is higher than radial flux. Maintaining a uniform sub-millimeter air gap across a large-diameter disc requires stiff structural design. Thermal management is also trickier — heat must be extracted radially rather than axially.
Dual-rotor / single-stator axial flux machine. Flux crosses two air gaps in parallel, with the entire disc diameter contributing to torque — the source of the topology's high torque density and short axial length.
Yokeless & Segmented: The YASA Topology
YASA (Yokeless And Segmented Armature) motors are a specialized axial flux variant developed by Dr. Tim Woolmer at Oxford University and commercialized through YASA Ltd., which was acquired by Mercedes-Benz in 2021. The breakthrough: eliminating the stator yoke entirely and using individually wound, segmented stator teeth.
Design Principle: Each stator segment is placed between two opposing rotor discs carrying permanent magnets. Flux from a north magnet on one rotor passes through the stator segment to a south magnet on the opposite rotor, then returns through the air. Each segment is an independent electromagnetic unit wound with concentrated coils on a grain-oriented silicon-steel core.
This architecture substantially reduces stator mass compared to conventional axial flux designs and reduces stator iron losses. YASA has publicly announced new prototype power-density milestones in recent years; readers should consult YASA's own press materials for the current vendor-reported figures, which continue to advance.
YASA layout: 12 independent segmented stator armatures sit between two opposing magnet-carrying rotor discs. Removing the stator yoke trims mass and iron losses while concentrated coils on grain-oriented Si-steel cores carry the flux from N → segment → S.
Printed Precision: PCB Stator Technology
PCB stator motors replace traditional wound copper coils with precisely etched copper traces on multi-layer printed circuit boards. Modern high-layer-count PCBs with heavy copper achieve competitive current densities for the right applications.
Design Principle: The stator is a rigid or flex PCB with spiral or wave-pattern copper traces forming the winding pattern. Permanent magnets on the rotor (often in a Halbach-like arrangement) concentrate flux on the stator side. The thin profile (single-digit millimeters for the stator alone) enables ultra-compact axial flux designs.
The manufacturing advantage is substantial: PCB fabrication is a mature, high-volume process. Stators can be produced at scale with micron-level precision, zero manual winding labor, and high repeatability. Embedded sensors, driver electronics, and even power stages can share the same PCB substrate, creating fully integrated smart motors.
Trade-offs: Peak torque density is generally lower than wound motors because copper fill factor in PCB traces trails wire-wound coils. Thermal limits are also tighter — standard FR4 substrate has a defined glass-transition temperature and high-temperature variants (such as polyimide) come at a cost premium.
A single layer of a multi-layer PCB stator. Three phases (A / B / C) are routed as nested arcs around the bore; in production stacks, multiple layers are interconnected with vias to build the equivalent of a wound coil, with zero hand winding.
Artificial Muscles: HASEL Actuators
HASEL (Hydraulically Amplified Self-healing Electrostatic) actuators represent a radical departure from electromagnetic motors. The foundational work was published by Acome, Mitchell, et al. in Science in 2018, originating in Prof. Christoph Keplinger's group (then at the University of Colorado Boulder). These soft actuators use electrostatic forces amplified by hydraulic redistribution of liquid dielectric to generate muscle-like motion.
Design Principle: A flexible polymer shell (typically heat-sealed BOPP film) is partially filled with a liquid dielectric. Electrodes on opposing sides of the pouch create electrostatic attraction when high voltage is applied, squeezing the dielectric fluid and causing the pouch to change shape.
The 'self-healing' property comes from the liquid dielectric: if dielectric breakdown occurs, the liquid flows back to fill the void, restoring insulation. Artimus Robotics, the CU Boulder spin-out, is commercializing HASEL actuators for haptic feedback, prosthetics, and robotic gripping. Current challenges include the high drive voltage (kilovolt range) and limited cycle life compared to electromagnetic motors.
HASEL pouch in two states. With voltage applied, electrodes ‘zip’ along the pouch edge and displace the liquid dielectric, contracting the actuator and lifting the load. Self-healing comes from the liquid backflow after a transient breakdown event.
Compliant Motion: Soft Robotic Actuators
Soft robotic actuators abandon rigid components entirely, using elastomeric materials that deform under pneumatic, hydraulic, or chemical stimulation to produce motion.
Design Principles: The most common type is the pneumatic network (PneuNet) actuator: a silicone body with internal chambers that inflate when pressurized, causing bending, twisting, or extension. McKibben muscles — braided mesh sleeves around inflatable bladders — contract linearly when pressurized, mimicking skeletal muscle.
Soft actuators excel where rigid motors fail: grasping delicate objects (fruit, organs), navigating confined spaces (endoscopy, pipeline inspection), and safe human interaction (wearable exosuits, rehabilitation devices). The trade-off is precision — controlling a continuously deformable body requires sophisticated sensing and increasingly machine learning for closed-loop control.
Companies like Soft Robotics Inc. (acquired by ABB in 2023) and Festo (with their Bionic line) have brought pneumatic grippers to commercial food packaging lines.
PneuNet bending actuator. A silicone body with sequential chambers is bonded to an inextensible strain-limiting layer; pressurization expands the chambers asymmetrically and the body curls toward the limiter — the basis for compliant grippers and continuum manipulators.
Brushed, Brushless, Stepper, Servo & Beyond
While the previous sections classified motors by flux topology (radial vs. axial vs. yokeless), engineers more commonly encounter motors classified by commutation and control method. These two classification axes are orthogonal — a BLDC motor can be radial flux or axial flux; a servo motor is typically a PMSM with a closed-loop controller.
The key insight: the motor and its controller form an inseparable system — choosing a motor without considering the drive electronics is like choosing a CPU without considering the instruction set.
BLDC vs. PMSM: Both are permanent magnet synchronous machines electronically commutated. BLDC motors have trapezoidal back-EMF and are traditionally driven with six-step commutation. PMSM motors have sinusoidal back-EMF and are driven with sinusoidal currents via Field-Oriented Control (FOC). The same physical motor can often be driven as either depending on the controller algorithm.
Stepper motors divide a full rotation into discrete steps (typically 200 steps/rev for hybrid steppers). With microstepping, effective resolution can reach a small fraction of a full step. The classic weakness is open-loop operation — under excessive load, the motor 'loses steps' with no feedback to detect the error.
AC induction motors remain among the most manufactured motor types globally. The rotor has no magnets — instead, the rotating stator field induces currents in rotor conductor bars (the 'squirrel cage'). Tesla notably used induction motors in early Model S configurations and has used a mix of induction and PMSM across the Model 3 lineup, with engineering rationales each company has discussed publicly.
Topology and control are orthogonal axes. Most flux topologies pair natively with PMSM (FOC) or BLDC (six-step) drive — steppers and induction sit slightly off the modern PM-machine mainstream but remain widespread in their own niches.
Why Actuator-First Companies Win in Robotics
A pattern emerges across the most influential robotics programs of the past two decades: the leaders almost always invested deeply in actuator design, not just algorithms. Boston Dynamics' custom hydraulic actuators gave Atlas and BigDog their distinctive agility years before reinforcement learning matured — and when they shifted to electric actuation for the new Atlas, the program centered on custom electric actuators rather than off-the-shelf motors.
The logic is straightforward: software can iterate weekly, but the physics of force, compliance, and bandwidth are bounded by hardware. Ben Katz's well-known MIT work on low-cost modular actuators demonstrated that proprioceptive actuators — high-torque, backdrivable motors with minimal gearing — could enable dynamic locomotion at a fraction of the cost of hydraulics. This actuator-first philosophy is widely cited as an influence on subsequent humanoid programs.
The implication for engineers: if you're building a physical system that interacts with the real world, the actuator is your most consequential design decision. Get the motor topology right — matching torque density, compliance, bandwidth, and cost to your application — and the rest of the system has room to evolve. Get it wrong, and no amount of software sophistication will compensate.
This is exactly why Handybot's 6-DoF telescopic arm and force-controlled tool changer are designed in-house rather than assembled from catalog parts — and it's the throughline that connects every post in our engineering series.
An indicative trade-off radar across four flux topologies. Higher is better on each axis. Radial flux dominates on cost / scalability / manufacturing simplicity; axial flux and YASA push power density and efficiency at the expense of cost and thermal complexity; PCB stators trade peak density for manufacturability and thinness.
